| PartZenbakia | G156XTN02.1 |
| Marka | AUO |
| Tamaina | 15.6 |
| Aplikazio | Industrial |
| Ebazpena | 1366×768 |
| Konposizioa | a-Si TFT-LCD, LCM |
| Distira | |
| CR | 600:1 |
| Koloreak | 262K |
| Atzeko argia | WLED |
| Interfazea | eDP |
| panel marka | AUO |
| panel eredua | G156XTN02.1 (AUO21EC) |
| panelaren tamaina | 15.6" |
| panel mota | a-Si TFT-LCD, LCM |
| ebazpena | 1366(RGB)×768, WXGA, 100PPI |
| pixel formatua | RGB Vertical Stripe |
| bistaratzeko eremua | 344.232(W)×193.536(H) mm |
| bezela irekidura | - |
| eskema tamaina | 359.5(W)×223.8(H) ×3.3(D) mm |
| azalera | Antiglare, Hard coating (3H) |
| distira | 250 cd/m² (Typ.) |
| kontraste-erlazioa | 600:1 (Typ.) (TM) |
| ikuspegi angelua | 80/80/55/70 (Typ.)(CR≥10) |
| bistaratzeko modua | TN, Normally White, Transmissive |
| ikuspegirik onena | 6 o'clock |
| erantzun denbora | 8 (Typ.)(Tr+Td) |
| bistaratzeko koloreak | 262K 45% NTSC |
| lanpara mota | WLED , 15K hours , With LED Driver |
| maiztasuna | 60Hz |
| pantaila taktila | Without |
| panelaren pisua | 380g (Max.) |
| aplikazio | Industrial |
| seinale interfazea | eDP (1 Lane) , eDP1.2 , 30 pins Connector |
| sarrerako tentsioa | 3.3V (Typ.) |
| ingurunea | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
