| PartZenbakia | G070VAN01.1 |
| Marka | AUO |
| Tamaina | 7.0 |
| Aplikazio | Industrial |
| Ebazpena | 800×480 |
| Konposizioa | LCM , a-Si TFT-LCD |
| Distira | |
| CR | 1300:1 |
| Koloreak | 262K/16.7M |
| Atzeko argia | 7S2P |
| Interfazea | LVDS |
| fabrikatzailea | AUO |
| pantailaren tamaina | 7.0 inch |
| pixel-zenbakia | 800×480(RGB) (WVGA) 133PPI |
| eremu aktiboa (mm) | 152.4 × 91.44 (H×V) |
| bezela eremua (mm) | 154.2 × 93.24 (H×V) |
| luminantzia | 200 cd/m² (Typ.) |
| ikuspegi angelua | 85/85/85/85 (Typ.)(CR≥10) |
| ikuspegi ona | Symmetry |
| kolore-sakonera | 262K/16.7M 60% NTSC |
| masa | 160g (Typ.) |
| freskatze tasa | 60Hz |
| seinale mota | LVDS (1 ch, 6/8-bit) , 30 pins Connector |
| tentsio-hornidura | 3.3V (Typ.) |
| gehienez. balorazioak | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
| ereduaren izena | G070VAN01.1 |
| pantaila mota | LCM , a-Si TFT-LCD |
| antolamendua | RGB Horizontal Stripe |
| eskema (mm) | 166.6 × 107 × 10 (H×V×D) |
| tratamendua | Antiglare |
| kontraste-erlazioa | 1300 : 1 (Typ.) (TM) |
| erantzuna | 11/19 (Max.)(Tr/Td) ms |
| lan egiteko modua | AHVA, Normally Black, Transmissive |
| atzeko argia | 7S2P WLED , 30K hours , No Driver |
| erabiltzen | Industrial |
| pantaila taktila | Without |
