| PartZenbakia | C090EAN04.1 |
| Marka | AUO |
| Tamaina | 9.0 |
| Aplikazio | Outdoor High Brightn |
| Ebazpena | 1280×720 |
| Konposizioa | a-Si TFT-LCD, LCM |
| Distira | |
| CR | 1000:1 |
| Koloreak | 16.7M |
| Atzeko argia | WLED |
| Interfazea | LVDS |
| marka | AUO |
| eredua | C090EAN04.1 |
| diagonalaren tamaina | 9.0 inch |
| mota | a-Si TFT-LCD, LCM |
| pixel formatua | 1280(RGB)×720 [WXGA] 163PPI |
| konfigurazioa | RGB Vertical Stripe |
| eremu aktiboa | 198.72(H)×111.78(V) mm |
| eskema dim. | 212.2(H)×127.9(V) ×11(D) mm |
| bezela eremua | 202.02(H)×115.78(V) mm |
| tratamendua | Antiglare |
| luminantzia | 900 cd/m² (Typ.) |
| kontraste-erlazioa | 1000:1 (Typ.) (TM) |
| ikusi norabidea | Symmetry |
| erantzun denbora | 30 (Typ.)(Tr+Td) |
| ikuspegi angelua | 80/80/80/80 (Typ.)(CR≥10) |
| funtzionamendu modua | AHVA, Normally Black, Transmissive |
| euskarria kolorea | 16.7M 72% NTSC |
| argi iturria | WLED [8S3P] , 10K hours , W/O Driver |
| pisua | TBD |
| entzat diseinatua | Outdoor High Brightness Automotive Display |
| fotograma-tasa | 60Hz |
| ukipen-panela | Without |
| interfaze mota | LVDS (1 ch, 8-bit) , 40 pins FPC |
| energia hornidura | 3.3V (Typ.) |
| ingurunea | Operating Temperature: -30 ~ 85 °C ; Storage Temperature: -40 ~ 95 °C ; Vibration Level: 2.9G (28.4 m/s²) |
| A090VW01 V3 | AUO | 9.0 | 800×480 |
| AA090ME01 | Mitsubishi | 9.0 | 800×480 |
| AT090TN23 | Innolux | 9.0 | 1280×800 |
| C090EAN01.1 | AUO | 9.0 | 1280×720 |
| ED090NA-01D | Innolux | 9.0 | 1280×800 |
| ED090NA-01H | Innolux | 9.0 | 1280×800 |
| LTA090A220F | TOSHIBA | 9.0 | 800×480 |
| LTA090B400F | TOSHIBA | 9.0 | 800×480 |
| NL192108AC10-01D | NLT | 9.0 | 1920×1080 |
| TX23D12VM0CAA | KOE | 9.0 | 800×480 |
