| PartZenbakia | C080VTN04.0 |
| Marka | AUO |
| Tamaina | 8.0 |
| Aplikazio | Automotive Display |
| Ebazpena | 800×480 |
| Konposizioa | a-Si TFT-LCD, LCM |
| Distira | |
| CR | |
| Koloreak | 262K |
| Atzeko argia | WLED |
| Interfazea | Parallel |
| marka | AUO |
| eredua | C080VTN04.0 |
| diagonalaren tamaina | 8.0 inch |
| mota | a-Si TFT-LCD, LCM |
| pixel formatua | 800(RGB)×480 [WVGA] 115PPI |
| konfigurazioa | RGB Vertical Stripe |
| eremu aktiboa | 175.2(H)×105.12(V) mm |
| eskema dim. | - |
| bezela eremua | - |
| tratamendua | Antiglare |
| ikusi norabidea | - |
| erantzun denbora | 15/20 (Typ.)(Tr/Td) |
| ikuspegi angelua | 60/60/40/60 (Typ.)(CR≥10) |
| funtzionamendu modua | TN, Normally White, Transmissive |
| euskarria kolorea | 262K |
| argi iturria | WLED |
| pisua | - |
| entzat diseinatua | Automotive Display |
| fotograma-tasa | 60Hz |
| ukipen-panela | - |
| interfaze mota | Parallel RGB (1 ch, 6-bit) , 60 pins Connector |
| ingurunea | Operating Temperature: -30 ~ 80 °C ; Storage Temperature: -40 ~ 95 °C |
