| PartZenbakia | C080EAN04.1 |
| Marka | AUO |
| Tamaina | 8.0 |
| Aplikazio | Automotive Display |
| Ebazpena | 1280×720 |
| Konposizioa | LCM, a-Si TFT-LCD |
| Distira | |
| CR | 1000:1 |
| Koloreak | 16.7M |
| Atzeko argia | 6S4P |
| Interfazea | |
| fabrikatzailea | AUO |
| ereduaren izena | C080EAN04.1 |
| pantailaren tamaina | 8.0 inch |
| pantaila mota | LCM, a-Si TFT-LCD |
| pixel-zenbakia | 1280(RGB)×720 (WXGA) 184PPI |
| antolamendua | RGB Vertical Stripe |
| eremu aktiboa (mm) | 176.64 × 99.36 (H×V) |
| eskema (mm) | 186.5 × 117.12 (H×V×D) |
| bezela eremua (mm) | 179.55 × 105.36 (H×V) |
| tratamendua | Antiglare |
| luminantzia | 750 cd/m² (Typ.) |
| kontraste-erlazioa | 1000 : 1 (Typ.) (TM) |
| ikuspegi angelua | 80/80/80/80 (Typ.)(CR≥10) |
| erantzuna | 20 (Max.)(Tr+Tf) ms |
| ikuspegi ona | Symmetry |
| lan egiteko modua | AHVA, Normally Black, Transmissive |
| kolore-sakonera | 16.7M 68% NTSC |
| atzeko argia | 6S4P WLED , 30K hours , No Driver |
| masa | 229±23g |
| erabiltzen | Automotive Display |
| freskatze tasa | 60Hz |
| pantaila taktila | Without |
| Storage Temp.: -40 ~ 95 °C Operating Temp.: -30 ~ 85 °C ; Vibration Level: 2.9G (28.4 m/s²) |
