| PartZenbakia | BA101WS1-100 |
| Marka | BOE |
| Tamaina | 10.1 |
| Aplikazio | NOPC |
| Ebazpena | 1024×600 |
| Konposizioa | LCM |
| Distira | 200 |
| CR | 500:1 |
| Koloreak | 262K |
| Atzeko argia | WLED |
| Interfazea | LVDS |
| panel marka | BOE |
| panel eredua | BA101WS1-100 5 Compatible model |
| panel mota | a-Si TFT-LCD , LCM |
| panelaren tamaina | 10.1 inch |
| ebazpena | 1024(RGB)×600 , WSVGA |
| bistaratzeko modua | TN, Normally White, Transmissive |
| eremu aktiboa | 222.72×125.28 mm |
| eskema | 245×146.5×3.6 mm |
| forma estiloa | Flat (PCBA Flat, Depth 3.4~4.0mm) |
| azalera | Glare (Haze 0%), Hard coating (3H) |
| distira | 200 cd/m² (Typ.) |
| kontraste-erlazioa | 500:1 (Typ.) |
| bistaratzeko koloreak | 262K (6-bit), CIE193145% |
| erantzun denbora | 8 (Typ.)(Tr+Td) |
| ikuspegi angelua | 45/45/15/35 (Typ.)(CR≥10)(L/R/U/D) |
| maiztasuna | 60Hz |
| lanpara mota | 6S4PWLEDEmbedded (LED Driver) |
| seinale interfazea | LVDS (1 ch, 6-bit), 40 pins |
| sarrerako tentsioa | 3.3V (Typ.) |
| aplikazio | NOPC |
| A101SW02 V1 | AUO | 10.1 | 1024×600 |
| B101EAN01.4 | AUO | 10.1 | 1280×800 |
| B101EAN01.5 | AUO | 10.1 | 1280×800 |
| BA101WS1-100 | BOE | 10.1 | 1024×600 |
| DLC1010AZG-1 | Other | 10.1 | 1024×600 |
| EJ101IA-02A | Innolux | 10.1 | 1280×800 |
| HSD100IFW1-A00 | HannStar | 10.1 | 1024×600 |
| HSD101PWW1-F01 | HannStar | 10.1 | 1280×800 |
| LTL101AL03-W01 | Samsung | 10.1 | 1280×800 |
| LTN101NT06-W03 | Samsung | 10.1 | 1024×600 |
| AT102TN42 | Innolux | 10.2 | 1024×600 |
| B089AW01 V2 | AUO | 8.9 | 1024×600 |
| B101AW02 V0 | AUO | 10.1 | 1024×600 |
| B116XTN02.3 HW4A | AUO | 11.6 | 1366×768 |
| B116XW02 V0 | AUO | 11.6 | 1366×768 |
| BT101IW04 V.0 | Innolux | 10.1 | 1024×600 |
| LP101WS1-TLA1 | LG Display | 10.1 | 1024×576 |
| LP101WSA-TLA1 | LG Display | 10.1 | 1024×600 |
| N116B6-L04 | Innolux | 11.6 | 1366×768 |
| N116BGE-L41 | Innolux | 11.6 | 1366×768 |
