| PartZenbakia | LP101WSA-TLA1 |
| Marka | LG Display |
| Tamaina | 10.1 |
| Aplikazio | NOPC |
| Ebazpena | 1024×600 |
| Konposizioa | LCM |
| Distira | 200 |
| CR | 300:1 |
| Koloreak | 262K |
| Atzeko argia | WLED |
| Interfazea | LVDS |
| panel marka | LG.Philips LCD |
| panel eredua | LP101WSA-TLA1 13 Compatible model |
| panel mota | a-Si TFT-LCD , LCM |
| panelaren tamaina | 10.1 inch |
| ebazpena | 1024(RGB)×600 , WSVGA |
| bistaratzeko modua | TN, Normally White, Transmissive |
| eremu aktiboa | 222.72×125.28 mm |
| eskema | 235×143×5.2 mm |
| forma estiloa | Wedge (PCBA Bent, Depth ≥5.2mm) |
| azalera | Glare (Haze 0%) |
| distira | 200 cd/m² (Typ.) |
| kontraste-erlazioa | 300:1 (Min.) |
| bistaratzeko koloreak | 262K (6-bit), CIE193145% |
| erantzun denbora | 16 (Typ.)(Tr+Td) |
| ikuspegi angelua | 30/30/10/20 (Min.)(CR≥10)(L/R/U/D) |
| maiztasuna | 60Hz |
| lanpara mota | WLEDEmbedded (LED Driver) |
| seinale interfazea | LVDS (1 ch, 6-bit), 40 pins |
| sarrerako tentsioa | 3.3V (Typ.) |
| aplikazio | NOPC |
