| PartZenbakia | LA070WV6-SD01 |
| Marka | LG Display |
| Tamaina | 7.0 |
| Aplikazio | CNS |
| Ebazpena | 800×480 |
| Konposizioa | LCM |
| Distira | 610 |
| CR | 1000:1 |
| Koloreak | 16.7M |
| Atzeko argia | WLED |
| Interfazea | TTL |
| panel marka | LG Display |
| panel eredua | LA070WV6-SD01 |
| panel mota | a-Si TFT-LCD , LCM |
| panelaren tamaina | 7.0 inch |
| ebazpena | 800(RGB)×480 , WVGA |
| bistaratzeko modua | IPS, Normally Black, Transmissive |
| eremu aktiboa | 152.4×91.44 mm |
| eskema | 166.6×105.8×10.5 mm |
| azalera | Antiglare (Haze 25%), Hard coating (3H) |
| distira | 610 cd/m² (Typ.) |
| kontraste-erlazioa | 1000:1 (Typ.) |
| bistaratzeko koloreak | 16.7M (8-bit), CIE193160% |
| erantzun denbora | 15/10 (Typ.)(Tr/Td) |
| ikuspegi angelua | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| maiztasuna | 60Hz |
| lanpara mota | 5S2PWLEDWithout Driver |
| seinale interfazea | Parallel RGB (1 ch, 6-bit), 66 pins |
| sarrerako tentsioa | 3.3/13.0/18.5/-7.5V (Typ.)(DVDD/AVDD/VGH/VGL) |
| aplikazio | CNS |
