| PartZenbakia | AM-800600MTMQW-50H |
| Marka | AMPIRE |
| Tamaina | 8.4 |
| Aplikazio | Industrial Outdoor H |
| Ebazpena | 800×600 |
| Konposizioa | a-Si TFT-LCD , LCM |
| Distira | |
| CR | 600:1 |
| Koloreak | 262K/16.7M |
| Atzeko argia | 6S5P |
| Interfazea | |
| panel marka | AMPIRE |
| panelaren tamaina | 8.4" |
| ebazpena | 800(RGB)×600, SVGA, 119PPI |
| bistaratzeko eremua | 170.4(W)×127.8(H) mm |
| eskema tamaina | 189.75(W)×149.4(H) ×5.3(D) mm |
| distira | 1000 cd/m² (Typ.) |
| ikuspegi angelua | 75/75/60/70 (Typ.)(CR≥10) |
| ikuspegirik onena | - |
| bistaratzeko koloreak | 262K/16.7M |
| maiztasuna | 60Hz |
| pisua | TBD |
| panel eredua | AM-800600MTMQW-50H |
| panel mota | a-Si TFT-LCD , LCM |
| pixel formatua | RGB Vertical Stripe |
| bezela irekidura | 173.4(W)×130.8(H) mm |
| azalera | - |
| kontraste-erlazioa | 600:1 (Typ.) (TM) |
| bistaratzeko modua | TN, Normally White, Transmissive |
| erantzun denbora | 8 (Typ.)(Tr+Td) |
| lanpara mota | 6S5P WLED , Without Driver |
| pantaila taktila | Without |
| aplikazio | Industrial Outdoor High Brightness |
