| PartZenbakia | AM-800600M3TNQW-02H |
| Marka | AMPIRE |
| Tamaina | 8.4 |
| Aplikazio | Industrial |
| Ebazpena | 800×600 |
| Konposizioa | LCM , a-Si TFT-LCD |
| Distira | |
| CR | 600:1 |
| Koloreak | 262K |
| Atzeko argia | 12S4P |
| Interfazea | LVDS |
| fabrikatzailea | AMPIRE |
| ereduaren izena | AM-800600M3TNQW-02H |
| pantailaren tamaina | 8.4 inch |
| pantaila mota | LCM , a-Si TFT-LCD |
| pixel-zenbakia | 800(RGB)×600 (SVGA) 119PPI |
| antolamendua | RGB Vertical Stripe |
| eremu aktiboa (mm) | 170.4 × 127.8 (H×V) |
| eskema (mm) | 203 × 145.5 × 10.4 (H×V×D) |
| bezela eremua (mm) | 174.15 × 131.2 (H×V) |
| tratamendua | - |
| luminantzia | 350 cd/m² (Typ.) |
| kontraste-erlazioa | 600 : 1 (Typ.) (TM) |
| ikuspegi angelua | 75/75/60/70 (Typ.)(CR≥10) |
| erantzuna | 8 (Typ.)(Tr+Td) ms |
| ikuspegi ona | - |
| lan egiteko modua | TN, Normally White, Transmissive |
| kolore-sakonera | 262K 70% NTSC |
| atzeko argia | 12S4P WLED , 50K hours , With LED Driver |
| masa | 280g |
| erabiltzen | Industrial |
| freskatze tasa | 60Hz |
| pantaila taktila | Without |
| seinale mota | LVDS (1 ch, 6-bit) , 20 pins Connector |
| tentsio-hornidura | 3.3V (Typ.) |
| gehienez. balorazioak | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
| AA084SD01 | Mitsubishi | 8.4 | 800×600 |
| AA084SD11 | Mitsubishi | 8.4 | 800×600 |
| AA084VB02 | Mitsubishi | 8.4 | 640×480 |
| AA084XB01 | Mitsubishi | 8.4 | 1024×768 |
| AM-800600M3TNQW-00H | AMPIRE | 8.4 | 800×600 |
| AM-800600M3TNQW-01H-F | AMPIRE | 8.4 | 800×600 |
| G084SN03 V3 | AUO | 8.4 | 800×600 |
| LTM08C351L | TOSHIBA | 8.4 | 800×600 |
| LTM08C355S | TOSHIBA | 8.4 | 800×600 |
| NL6448BC26-27 | NLT | 8.4 | 640×480 |
