| PartZenbakia | AM-800480R2TMQW-U0H |
| Marka | AMPIRE |
| Tamaina | 7.0 |
| Aplikazio | Industrial |
| Ebazpena | 800×480 |
| Konposizioa | LCM , a-Si TFT-LCD |
| Distira | |
| CR | 250:1 |
| Koloreak | 65K |
| Atzeko argia | WLED |
| Interfazea | UART |
| fabrikatzailea | AMPIRE |
| ereduaren izena | AM-800480R2TMQW-U0H |
| pantailaren tamaina | 7.0 inch |
| pantaila mota | LCM , a-Si TFT-LCD |
| pixel-zenbakia | 800(RGB)×480 (WVGA) 133PPI |
| antolamendua | RGB Vertical Stripe |
| eremu aktiboa (mm) | 152.4 × 91.44 (H×V) |
| eskema (mm) | 178.5 × 110 × 20.4 (H×V×D) |
| bezela eremua (mm) | 155.3 × 94.3 (H×V) |
| tratamendua | - |
| luminantzia | 400 cd/m² (Typ.) |
| kontraste-erlazioa | 250 : 1 (Typ.) (TM) |
| ikuspegi angelua | 70/70/60/60 (Typ.)(CR≥10) |
| erantzuna | 50 (Typ.)(Tr+Td) ms |
| ikuspegi ona | - |
| lan egiteko modua | TN, Normally White, Transmissive |
| kolore-sakonera | 65K 48% NTSC |
| atzeko argia | WLED , With LED Driver |
| masa | - |
| erabiltzen | Industrial |
| freskatze tasa | - |
| pantaila taktila | Without |
| seinale mota | UART , 8 pins Connector |
| tentsio-hornidura | 4.6/26.0V (Min./Typ.) |
| gehienez. balorazioak | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
