| PartZenbakia | AM-800480N3TZQW-57H |
| Marka | AMPIRE |
| Tamaina | 5.0 |
| Aplikazio | Industrial Automotiv |
| Ebazpena | 800×480 |
| Konposizioa | LCM, a-Si TFT-LCD |
| Distira | |
| CR | 1000:1 |
| Koloreak | 262K |
| Atzeko argia | 3S6P |
| Interfazea | |
| fabrikatzailea | AMPIRE |
| ereduaren izena | AM-800480N3TZQW-57H |
| pantailaren tamaina | 5.0 inch |
| pantaila mota | LCM, a-Si TFT-LCD |
| pixel-zenbakia | 800(RGB)×480 (WVGA) 188PPI |
| antolamendua | RGB Vertical Stripe |
| eremu aktiboa (mm) | 108 × 64.8 (H×V) |
| eskema (mm) | 119.7 × 78.3 × 10.05 (H×V×D) |
| bezela eremua (mm) | 109.6 × 66.4 (H×V) |
| tratamendua | - |
| luminantzia | 1000 cd/m² (Typ.) |
| kontraste-erlazioa | 1000 : 1 (Typ.) (TM) |
| ikuspegi angelua | 85/85/85/85 (Typ.)(CR≥10) |
| erantzuna | 30 (Typ.)(Tr+Td) ms |
| ikuspegi ona | Symmetry |
| lan egiteko modua | IPS, Normally Black, Transmissive |
| kolore-sakonera | 262K |
| atzeko argia | 3S6P WLED , 50K hours , With LED Driver |
| masa | - |
| erabiltzen | Industrial Automotive Display |
| freskatze tasa | 60Hz |
| pantaila taktila | Without |
| Storage Temp.: -30 ~ 85 °C Operating Temp.: -30 ~ 85 °C |
