| PartZenbakia | AM-800480LTMQW-WAH |
| Marka | AMPIRE |
| Tamaina | 5.0 |
| Aplikazio | Industrial |
| Ebazpena | 800×480 |
| Konposizioa | a-Si TFT-LCD, LCM |
| Distira | |
| CR | 500:1 |
| Koloreak | 262K |
| Atzeko argia | WLED |
| Interfazea | CPU |
| marka | AMPIRE |
| eredua | AM-800480LTMQW-WAH |
| diagonalaren tamaina | 5.0 inch |
| mota | a-Si TFT-LCD, LCM |
| pixel formatua | 800(RGB)×480 [WVGA] 188PPI |
| konfigurazioa | RGB Vertical Stripe |
| eremu aktiboa | 108(H)×64.8(V) mm |
| eskema dim. | 118.5(H)×77.1(V) ×6.37(D) mm |
| bezela eremua | 110.6(H)×67.4(V) mm |
| tratamendua | - |
| luminantzia | 470 cd/m² (Typ.) |
| kontraste-erlazioa | 500:1 (Typ.) (TM) |
| ikusi norabidea | - |
| erantzun denbora | 15/35 (Typ.)(Tr/Td) |
| ikuspegi angelua | 70/70/70/50 (Typ.)(CR≥10) |
| funtzionamendu modua | TN, Normally White, Transmissive |
| euskarria kolorea | 262K 52% NTSC |
| argi iturria | WLED [3S6P] , With LED Driver |
| pisua | TBD |
| entzat diseinatua | Industrial |
| fotograma-tasa | 60Hz |
| ukipen-panela | Without |
| interfaze mota | CPU , 40 pins Connector |
| energia hornidura | 3.3V (Typ.) |
| ingurunea | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
