| PartZenbakia | AM-800480CTZQW-A5H |
| Marka | AMPIRE |
| Tamaina | 7.0 |
| Aplikazio | Industrial Outdoor H |
| Ebazpena | 800×480 |
| Konposizioa | LCM , a-Si TFT-LCD |
| Distira | |
| CR | 1000:1 |
| Koloreak | 262K |
| Atzeko argia | 6S5P |
| Interfazea | LVDS |
| fabrikatzailea | AMPIRE |
| ereduaren izena | AM-800480CTZQW-A5H |
| pantailaren tamaina | 7.0 inch |
| pantaila mota | LCM , a-Si TFT-LCD |
| pixel-zenbakia | 800(RGB)×480 (WVGA) 133PPI |
| antolamendua | RGB Vertical Stripe |
| eremu aktiboa (mm) | 152.4 × 91.44 (H×V) |
| eskema (mm) | 165 × 104.4 × 11.61 (H×V×D) |
| bezela eremua (mm) | 15.48 × 93.85 (H×V) |
| tratamendua | - |
| luminantzia | 1500 cd/m² (Typ.) |
| kontraste-erlazioa | 1000 : 1 (Typ.) (TM) |
| ikuspegi angelua | 80/80/80/80 (Typ.)(CR≥10) |
| erantzuna | 25 (Typ.)(Tr+Td) ms |
| ikuspegi ona | Symmetry |
| lan egiteko modua | IPS, Normally Black, Transmissive |
| kolore-sakonera | 262K 58% NTSC |
| atzeko argia | 6S5P WLED , 50K hours , With LED Driver |
| masa | - |
| erabiltzen | Industrial Outdoor High Brightness |
| freskatze tasa | 60Hz |
| pantaila taktila | Without |
| seinale mota | LVDS (1 ch, 6-bit) , 20 pins Connector |
| tentsio-hornidura | 12.0V (Typ.) |
| gehienez. balorazioak | Storage Temp.: -30 ~ 85 °C Operating Temp.: -30 ~ 85 °C |
