| PartZenbakia | AM-320240N1TMQW-TW0H-A(R) |
| Marka | AMPIRE |
| Tamaina | 5.7 |
| Aplikazio | Industrial |
| Ebazpena | 320×240 |
| Konposizioa | LCM, a-Si TFT-LCD |
| Distira | |
| CR | 350:1 |
| Koloreak | 65K/262K |
| Atzeko argia | 3S7P |
| Interfazea | |
| fabrikatzailea | AMPIRE |
| ereduaren izena | AM-320240N1TMQW-TW0H-A(R) |
| pantailaren tamaina | 5.7 inch |
| pantaila mota | LCM, a-Si TFT-LCD |
| pixel-zenbakia | 320(RGB)×240 (QVGA) 70PPI |
| antolamendua | RGB Vertical Stripe |
| eremu aktiboa (mm) | 115.2 × 86.4 (H×V) |
| eskema (mm) | 167 × 109 × 14.8 (H×V×D) |
| bezela eremua (mm) | 118.2 × 89.4 (H×V) |
| tratamendua | - |
| luminantzia | 400 cd/m² (Typ.) |
| kontraste-erlazioa | 350 : 1 (Min.) (TM) |
| ikuspegi angelua | 70/70/50/70 (Typ.)(CR≥10) |
| erantzuna | 15/35 (Typ.)(Tr/Td) ms |
| ikuspegi ona | 6 o'clock |
| lan egiteko modua | TN, Normally White, Transmissive |
| kolore-sakonera | 65K/262K 61% NTSC |
| atzeko argia | 3S7P WLED , No Driver |
| masa | TBD |
| erabiltzen | Industrial |
| freskatze tasa | 60Hz |
| pantaila taktila | 4-wire Resistive Touch |
| Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
| AM-320240N1TMQW-T30H-D(R) | AMPIRE | 5.7 | 320×240 |
| CLAA057VC01CW | CPT | 5.7 | 640×480 |
| EL320.240.36 HB | Lumineq | 5.7 | 320×240 |
| G057QTN01.1 | AUO | 5.7 | 320×240 |
| H572DAN01.2 | AUO | 5.7 | 1080×1920 |
| LQ057V3LG11 | SHARP | 5.7 | 640×480 |
| MST-G320240DBSW-213W-E | Other | 5.7 | 320×240 |
| NL6448BC18-06F | NLT | 5.7 | 640×480 |
| SP14Q001 | KOE | 5.7 | 320×240 |
| TCG057QVLAC-G00 | Kyocera | 5.7 | 320×240 |
