| PartZenbakia | AM-320240LQTZQW-50H |
| Marka | AMPIRE |
| Tamaina | 3.5 |
| Aplikazio | Industrial Outdoor H |
| Ebazpena | 320×240 |
| Konposizioa | a-Si TFT-LCD , LCM |
| Distira | |
| CR | 1000:1 |
| Koloreak | 16.7M |
| Atzeko argia | 6S2P |
| Interfazea | Parallel |
| panel marka | AMPIRE |
| panelaren tamaina | 3.5" |
| ebazpena | 320(RGB)×240, QVGA, 115PPI |
| bistaratzeko eremua | 70.08(W)×52.56(H) mm |
| eskema tamaina | 76.9(W)×63.9(H) ×3.45(D) mm |
| distira | 800 cd/m² (Typ.) |
| ikuspegi angelua | 85/85/85/85 (Typ.)(CR≥10) |
| ikuspegirik onena | Symmetry |
| bistaratzeko koloreak | 16.7M 60% NTSC |
| maiztasuna | 60Hz |
| panelaren pisua | - |
| seinale interfazea | Parallel RGB (1 ch, 8-bit) + SPI , 50 pins FPC |
| sarrerako tentsioa | 3.3V (Typ.) |
| ingurunea | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
| panel eredua | AM-320240LQTZQW-50H |
| panel mota | a-Si TFT-LCD , LCM |
| pixel formatua | RGB Vertical Stripe |
| bezela irekidura | 72.88(W)×54.94(H) mm |
| azalera | - |
| kontraste-erlazioa | 1000:1 (Typ.) (TM) |
| bistaratzeko modua | Normally Black, Transmissive |
| erantzun denbora | 30 (Typ.)(Tr+Td) |
| lanpara mota | 6S2P WLED , 36K hours , Without Driver |
| pantaila taktila | Without |
| aplikazio | Industrial Outdoor High Brightness Instruments & Meters |
