| PartZenbakia | AM-19201200GTZQW-30H |
| Marka | AMPIRE |
| Tamaina | 10.1 |
| Aplikazio | Industrial Outdoor H |
| Ebazpena | 1920×1200 |
| Konposizioa | a-Si TFT-LCD, LCM |
| Distira | |
| CR | 800:1 |
| Koloreak | 16.7M |
| Atzeko argia | WLED |
| Interfazea | LVDS |
| marka | AMPIRE |
| eredua | AM-19201200GTZQW-30H |
| diagonalaren tamaina | 10.1 inch |
| mota | a-Si TFT-LCD, LCM |
| pixel formatua | 1920(RGB)×1200 [WUXGA] 224PPI |
| konfigurazioa | RGB Vertical Stripe |
| eremu aktiboa | 217.44(H)×135.9(V) mm |
| eskema dim. | - |
| luminantzia | 1000 cd/m² (Typ.) |
| kontraste-erlazioa | 800:1 (Typ.) (TM) |
| ikusi norabidea | Symmetry |
| erantzun denbora | 50 (Max.)(Tr+Td) |
| ikuspegi angelua | 80/80/80/80 (Typ.)(CR≥10) |
| funtzionamendu modua | AHVA, Normally Black, Transmissive |
| euskarria kolorea | 16.7M 57% NTSC |
| argi iturria | WLED , 50K hours , W/O Driver |
| pisua | - |
| entzat diseinatua | Industrial Outdoor High Brightness |
| fotograma-tasa | 60Hz |
| ukipen-panela | Without |
| interfaze mota | LVDS (2 ch, 8-bit) , 45 pins Connector |
| energia hornidura | 3.3V (Typ.) |
| ingurunea | Operating Temperature: -30 ~ 80 °C ; Storage Temperature: -30 ~ 80 °C |
