| PartZenbakia | AM-1280800NGTZQW-17H |
| Marka | AMPIRE |
| Tamaina | 10.1 |
| Aplikazio | Industrial Outdoor H |
| Ebazpena | 1280×800 |
| Konposizioa | a-Si TFT-LCD , LCM |
| Distira | |
| CR | 800:1 |
| Koloreak | 16.7M |
| Atzeko argia | 7S6P |
| Interfazea | LVDS |
| panel marka | AMPIRE |
| panelaren tamaina | 10.1" |
| ebazpena | 1280(RGB)×800, WXGA, 149PPI |
| bistaratzeko eremua | 216.96(W)×135.6(H) mm |
| eskema tamaina | 231(W)×154.4(H) ×6.2(D) mm |
| distira | 1500 cd/m² (Typ.) |
| ikuspegi angelua | 85/85/85/85 (Typ.)(CR≥10) |
| ikuspegirik onena | Symmetry |
| bistaratzeko koloreak | 16.7M 45% NTSC |
| maiztasuna | 60Hz |
| panelaren pisua | TBD |
| seinale interfazea | LVDS (1 ch, 8-bit) , 40 pins Connector |
| sarrerako tentsioa | 3.3V (Typ.) |
| ingurunea | Operating Temp.: -30 ~ 80 °C ; Storage Temp.: -30 ~ 80 °C |
| panel eredua | AM-1280800NGTZQW-17H |
| panel mota | a-Si TFT-LCD , LCM |
| pixel formatua | RGB Vertical Stripe |
| bezela irekidura | 220.76(W)×140.4(H) mm |
| azalera | Hard coating |
| kontraste-erlazioa | 800:1 (Typ.) (TM) |
| bistaratzeko modua | IPS, Normally Black, Transmissive |
| erantzun denbora | 25 (Typ.)(Tr+Td) |
| lanpara mota | 7S6P WLED , 50K hours , Without Driver |
| pantaila taktila | Without |
| aplikazio | Industrial Outdoor High Brightness |
