| PartZenbakia | AM-1024600ITZQW-00H |
| Marka | AMPIRE |
| Tamaina | 10.1 |
| Aplikazio | Industrial |
| Ebazpena | 1024×600 |
| Konposizioa | a-Si TFT-LCD, LCM |
| Distira | |
| CR | 500:1 |
| Koloreak | 262K/16.7M |
| Atzeko argia | WLED |
| Interfazea | LVDS |
| panel marka | AMPIRE |
| panel eredua | AM-1024600ITZQW-00H |
| panelaren tamaina | 10.1" |
| panel mota | a-Si TFT-LCD, LCM |
| ebazpena | 1024(RGB)×600, WSVGA, 117PPI |
| pixel formatua | RGB Vertical Stripe |
| bistaratzeko eremua | 222.72(W)×125.28(H) mm |
| bezela irekidura | - |
| eskema tamaina | 234.9(W)×143(H) ×4.9(D) mm |
| azalera | Antiglare, Hard coating |
| distira | 550 cd/m² (Typ.) |
| kontraste-erlazioa | 500:1 (Typ.) (TM) |
| ikuspegi angelua | 89/89/89/89 (Typ.)(CR≥10) |
| bistaratzeko modua | IPS, Normally Black, Transmissive |
| ikuspegirik onena | Symmetry |
| erantzun denbora | 12/28 (Typ.)(Tr/Td) |
| bistaratzeko koloreak | 262K/16.7M 70% NTSC |
| lanpara mota | WLED , 50K hours , Without Driver |
| maiztasuna | 60Hz |
| pantaila taktila | Without |
| panelaren pisua | - |
| aplikazio | Industrial |
| seinale interfazea | LVDS (1 ch, 6/8-bit) , 40 pins Connector |
| sarrerako tentsioa | 3.3/12.5/20/-10V (Typ.)(VDD/AVDD/VGH/VGL) |
| ingurunea | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
