| PartZenbakia | ACX565AKM-7 |
| Marka | SONY |
| Tamaina | 3.5 |
| Aplikazio | MPH |
| Ebazpena | 800×480 |
| Konposizioa | LCM |
| Distira | 275 |
| CR | 500:1 |
| Koloreak | 16.7M |
| Atzeko argia | WLED |
| Interfazea | CDP |
| panel marka | SONY |
| panel eredua | ACX565AKM-7 |
| panel mota | LTPS TFT-LCD , LCM |
| panelaren tamaina | 3.5 inch |
| ebazpena | 800(RGB)×480 , WVGA |
| bistaratzeko modua | VSPEC II, Normally Black, Transflective |
| eremu aktiboa | 76.8×46.08 mm |
| eskema | 87.9×52.18 mm |
| azalera | |
| distira | 275 cd/m² (Typ.) |
| kontraste-erlazioa | 500:1 (Typ.)(Transmissive)24:1 (Typ.)(Reflective) |
| bistaratzeko koloreak | 16.7M (8-bit), CIE193170% |
| erantzun denbora | 12/7 (Typ.)(Tr/Td) |
| ikuspegi angelua | |
| maiztasuna | 60Hz |
| lanpara mota | 3S2PWLEDWithout Driver |
| seinale interfazea | CDP (2 Lane) + SPI, 24 pins |
| sarrerako tentsioa | 1.8/2.75V (Typ.)(VDDI/VDD) |
| aplikazio | MPH |
| 35QVW1T | SII | 3.5 | 320×240 |
| 35WVF0H | SII | 3.5 | 480×800 |
| A035CN02 V1 | AUO | 3.5 | 480×234 |
| ACX565AKM-7 | SONY | 3.5 | 800×480 |
| ACX567AKM-7 | SONY | 3.2 | 320×480 |
| AM-320240LATNQW-00H-F | AMPIRE | 3.5 | 320×240 |
| NL2432DR22-02B | NLT | 3.5 | 240×320 |
| T-55343GD035JU-LW-AFN | Kyocera | 3.5 | 320×240 |
| TD035SHED1 | TPO | 3.5 | 480×640 |
| TM035KDH05 | Tianma | 3.5 | 320×240 |
| ACX565AKM-7 | SONY | 3.5 | 800×480 |
| AMDM001 | Samsung | 2.6 | 240×400 |
| DLC0350TZG | Other | 3.5 | 240×320 |
| ET028002DHU | EDT | 2.8 | 240×320 |
| LH400WV3-SD05 | LG Display | 4.0 | 480×800 |
| LTM024DC9B | TOSHIBA | 2.4 | 240×320 |
| LTM030DH60 | TOSHIBA | 3.0 | 240×427 |
| OEL9M0053-Y-E | Other | 1.6 | 128×64 |
| PJ045IC-01F | Innolux | 4.5 | 720×1280 |
| TM030LBHT1 | Tianma | 3.0 | 240×400 |
