| PartZenbakia | A035QN01 V4 |
| Marka | AUO |
| Tamaina | 3.5 |
| Aplikazio | DSC |
| Ebazpena | 320×240 |
| Konposizioa | LCM |
| Distira | 350 |
| CR | 350:1 |
| Koloreak | 16.7M |
| Atzeko argia | WLED |
| Interfazea | TTL |
| panel marka | AUO |
| panel eredua | A035QN01 V4 |
| panel mota | a-Si TFT-LCD , LCM |
| panelaren tamaina | 3.5 inch |
| ebazpena | 320(RGB)×240 , QVGA |
| bistaratzeko modua | TN, Normally White, Transmissive |
| eremu aktiboa | 70.08×52.56 mm |
| eskema | 76.9×63.9×4.43 mm |
| azalera | Hard coating (3H) |
| distira | 350 cd/m² (Typ.) |
| kontraste-erlazioa | 350:1 (Typ.) |
| bistaratzeko koloreak | 16.7M (8-bit), CIE193160% |
| erantzun denbora | 10/15 (Typ.)(Tr/Td) |
| ikuspegi angelua | 60/60/50/55 (Typ.)(CR≥10)(L/R/U/D) |
| maiztasuna | 60Hz |
| lanpara mota | 6S1PWLEDWithout Driver |
| seinale interfazea | Parallel RGB (1 ch, 8-bit) + SPI, 54 pins |
| sarrerako tentsioa | 3.3/5.0/16/-10V (Typ.)(VDD/AVDD/VGH/VGL) |
| aplikazio | DSC |
