| PartZenbakia | UG-9616TSWBG01 |
| Marka | WiseChip |
| Tamaina | 0.84 |
| Aplikazio | IA |
| Ebazpena | 96×16 |
| Konposizioa | OLED |
| Distira | 120 |
| CR | 10000:1 |
| Koloreak | Mono(White) |
| Atzeko argia | self |
| Interfazea | I²C |
| panel marka | WiseChip |
| panel eredua | UG-9616TSWBG01 |
| panel mota | PM-OLED , OLED |
| panelaren tamaina | 0.84 inch |
| ebazpena | 96×16 |
| eremu aktiboa | 21.104×3.504 mm |
| eskema | 29.1×9.2×1.4 mm |
| azalera | |
| distira | 120 cd/m² (Typ.) |
| kontraste-erlazioa | 10000 : 1 (Typ.) |
| bistaratzeko koloreak | Mono(White) (1-bit) |
| ikuspegi angelua | |
| gidariaren ic | Built-in SSD1306 |
| seinale interfazea | I²C, 14 pins |
| sarrerako tentsioa | 2.8/7.25V (Typ.)(VDD/VCC) |
| aplikazio | IA |
