| PartZenbakia | TV101WXM-AG0 |
| Marka | BOE |
| Tamaina | 10.1 |
| Aplikazio | Pad & Tablet |
| Ebazpena | 800×1280 |
| Konposizioa | Assembly , a-Si TF |
| Distira | |
| CR | 1000:1 |
| Koloreak | 16.7M |
| Atzeko argia | 6S6P |
| Interfazea | MIPI |
| fabrikatzailea | BOE |
| ereduaren izena | TV101WXM-AG0 |
| pantailaren tamaina | 10.1 inch |
| pantaila mota | Assembly , a-Si TFT-LCD |
| pixel-zenbakia | 800(RGB)×1280 (WXGA) 150PPI |
| antolamendua | RGB Vertical Stripe |
| eremu aktiboa (mm) | 135.322 × 216.463 (H×V) |
| eskema (mm) | 164 × 245.2 (H×V×D) |
| bezela eremua (mm) | - |
| tratamendua | Anti Fingerprint, Hard coating (7H) |
| luminantzia | 400 cd/m² (Typ.) |
| kontraste-erlazioa | 1000 : 1 (Typ.) (TM) |
| ikuspegi angelua | 85/85/85/85 (Typ.)(CR≥10) |
| erantzuna | 30 (Typ.)(Tr+Td) ms |
| ikuspegi ona | Symmetry |
| lan egiteko modua | - |
| kolore-sakonera | 16.7M 57% NTSC |
| atzeko argia | 6S6P WLED , 15K hours , No Driver |
| masa | 300g (Max.) |
| erabiltzen | Pad & Tablet |
| freskatze tasa | 60Hz |
| pantaila taktila | PCAP |
| seinale mota | MIPI (4 data lanes) , 51 pins Connector |
| tentsio-hornidura | 3.3/5.5/-5.5V (Typ.)(VDDIO/AVDD/AVEE) |
| gehienez. balorazioak | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
