| PartZenbakia | TV097QXM-NW0 |
| Marka | BOE |
| Tamaina | 9.7 |
| Aplikazio | Pad & Tablet |
| Ebazpena | 1536×2048 |
| Konposizioa | a-Si TFT-LCD, LCM |
| Distira | |
| CR | 1500:1 |
| Koloreak | 16.7M |
| Atzeko argia | 6S6P |
| Interfazea | MIPI |
| panel marka | BOE |
| panel eredua | TV097QXM-NW0 |
| panelaren tamaina | 9.7" |
| panel mota | a-Si TFT-LCD, LCM |
| ebazpena | 1536(RGB)×2048, QXGA, 264PPI |
| pixel formatua | RGB Vertical Stripe |
| bistaratzeko eremua | 147.456(W)×196.608(H) mm |
| bezela irekidura | - |
| eskema tamaina | 152.536(W)×206.548(H) ×4.5(D) mm |
| azalera | - |
| distira | 350 cd/m² (Typ.) |
| kontraste-erlazioa | 1500:1 (Typ.) (TM) |
| ikuspegi angelua | 85/85/85/85 (Min.)(CR≥10) |
| bistaratzeko modua | ADS, Normally Black, Transmissive |
| ikuspegirik onena | Symmetry |
| erantzun denbora | 35 (Max.)(Tr+Td) |
| bistaratzeko koloreak | 16.7M 70% NTSC |
| lanpara mota | 6S6P WLED , Without Driver |
| maiztasuna | 60Hz |
| pantaila taktila | Without |
| panelaren pisua | 135g (Max.) |
| aplikazio | Pad & Tablet |
| seinale interfazea | MIPI (4 data lanes) , 61 pins Connector |
| sarrerako tentsioa | 1.8/5.5/-5.5V (Typ.)(VDDI/AVDD/AVEE) |
| ingurunea | Operating Temp.: -10 ~ 60 °C ; Storage Temp.: -30 ~ 70 °C |
