| PartZenbakia | TV080WUM-NH1 |
| Marka | BOE |
| Tamaina | 8.0 |
| Aplikazio | Pad & Tablet |
| Ebazpena | 1200×1920 |
| Konposizioa | a-Si TFT-LCD, LCM |
| Distira | |
| CR | 850:1 |
| Koloreak | 16.7M |
| Atzeko argia | WLED |
| Interfazea | MIPI |
| marka | BOE |
| eredua | TV080WUM-NH1 |
| diagonalaren tamaina | 8.0 inch |
| mota | a-Si TFT-LCD, LCM |
| pixel formatua | 1200(RGB)×1920 [WUXGA] 283PPI |
| konfigurazioa | RGB Vertical Stripe |
| eremu aktiboa | 107.64(H)×172.224(V) mm |
| eskema dim. | - |
| luminantzia | - |
| kontraste-erlazioa | 850:1 (Typ.) (TM) |
| ikusi norabidea | Symmetry |
| erantzun denbora | 25 (Typ.)(Tr+Td) |
| ikuspegi angelua | 85/85/85/85 (Typ.)(CR≥10) |
| funtzionamendu modua | ADS, Normally Black, Transmissive |
| euskarria kolorea | 16.7M |
| argi iturria | WLED |
| pisua | - |
| entzat diseinatua | Pad & Tablet |
| fotograma-tasa | 60Hz |
| ukipen-panela | - |
| interfaze mota | MIPI (4 data lanes) , 39 pins Connector |
| energia hornidura | 3.3V (Typ.) |
| ingurunea | Operating Temperature: -20 ~ 60 °C ; Storage Temperature: -20 ~ 60 °C |
