| PartZenbakia | TV070WSM-NM0 |
| Marka | BOE |
| Tamaina | 7.0 |
| Aplikazio | Pad & Tablet |
| Ebazpena | 1024×600 |
| Konposizioa | a-Si TFT-LCD, LCM |
| Distira | |
| CR | 900:1 |
| Koloreak | 16.7M |
| Atzeko argia | WLED |
| Interfazea | MIPI |
| panel marka | BOE |
| panel eredua | TV070WSM-NM0 |
| panelaren tamaina | 7.0" |
| panel mota | a-Si TFT-LCD, LCM |
| ebazpena | 1024(RGB)×600, WSVGA, 169PPI |
| pixel formatua | RGB Vertical Stripe |
| bistaratzeko eremua | 153.6(W)×90(H) mm |
| bezela irekidura | - |
| eskema tamaina | 161.16(W)×100.97(H) ×4.8(D) mm |
| azalera | Glare (Haze 0%), Hard coating (3H) |
| distira | 450 cd/m² (Typ.) |
| kontraste-erlazioa | 900:1 (Typ.) (TM) |
| ikuspegi angelua | 85/85/85/85 (Typ.)(CR≥10) |
| bistaratzeko modua | ADS, Normally Black, Transmissive |
| ikuspegirik onena | Symmetry |
| erantzun denbora | 30 (Typ.)(Tr+Td) |
| bistaratzeko koloreak | 16.7M 50% NTSC |
| lanpara mota | WLED , Without Driver |
| maiztasuna | 60Hz |
| pantaila taktila | Without |
| panelaren pisua | 90.0g (Max.) |
| aplikazio | Pad & Tablet |
| seinale interfazea | MIPI (4 data lanes) , 40 pins Connector |
| sarrerako tentsioa | 1.8/3.3/9/19/-7V (Typ.)(VDD1/VDD3/AVDD/VGH/VGL) |
| ingurunea | Operating Temp.: -20 ~ 65 °C ; Storage Temp.: -40 ~ 85 °C |
