| PartZenbakia | TPM0501010P |
| Marka | JDI |
| Tamaina | 5.0 |
| Aplikazio | Mobile Phone |
| Ebazpena | 1080×1920 |
| Konposizioa | a-Si TFT-LCD, LCM |
| Distira | |
| CR | 1000:1 |
| Koloreak | 16.7M |
| Atzeko argia | WLED |
| Interfazea | MIPI |
| marka | JDI |
| eredua | TPM0501010P |
| diagonalaren tamaina | 5.0 inch |
| mota | a-Si TFT-LCD, LCM |
| pixel formatua | 1080(RGB)×1920 [FHD] 445PPI |
| konfigurazioa | RGB Vertical Stripe |
| eremu aktiboa | 61.641(H)×109.584(V) mm |
| eskema dim. | 64.04(H)×116.52(V) ×1.48(D) mm |
| luminantzia | 450 cd/m² (Typ.) |
| kontraste-erlazioa | 1000:1 (Typ.) (TM) |
| ikusi norabidea | Symmetry |
| erantzun denbora | 25 (Typ.)(Tr+Td) |
| ikuspegi angelua | 80/80/80/80 (Typ.)(CR≥10) |
| funtzionamendu modua | IPS, Normally Black, Transmissive |
| euskarria kolorea | 16.7M 85% NTSC |
| argi iturria | WLED [7S2P] , W/O Driver |
| pisua | TBD |
| entzat diseinatua | Mobile Phone |
| fotograma-tasa | 60Hz |
| ukipen-panela | In-Cell Touch |
| interfaze mota | MIPI (4 data lanes) , 40 pins Connector |
| energia hornidura | 1.8/5.5/-5.5V (Typ.)(IOVCC/AVDD/AVEE) |
| ingurunea | Operating Temperature: -20 ~ 60 °C ; Storage Temperature: -30 ~ 70 °C |
