| PartZenbakia | TMS150XG1-10TB Rev.E |
| Marka | Tianma |
| Tamaina | 15.0 |
| Aplikazio | DMPC |
| Ebazpena | 1024×768 |
| Konposizioa | LCM |
| Distira | 250 |
| CR | 600:1 |
| Koloreak | 16.7M |
| Atzeko argia | CCFL |
| Interfazea | LVDS |
| panel marka | AVIC |
| panel eredua | TMS150XG1-10TB Rev.E |
| panel mota | a-Si TFT-LCD , LCM |
| panelaren tamaina | 15.0 inch |
| ebazpena | 1024(RGB)×768 , XGA |
| bistaratzeko modua | TN, Normally White, Transmissive |
| eremu aktiboa | 304.128×228.096 mm |
| eskema | 326.5×253.5 mm |
| azalera | Antiglare, Hard coating |
| distira | 250 cd/m² (Typ.) |
| kontraste-erlazioa | 600:1 (Typ.) |
| bistaratzeko koloreak | 16.7M (6-bit + Hi-FRC), CIE193160% |
| erantzun denbora | 8 (Typ.)(Tr+Td) |
| ikuspegi angelua | 45/45/25/45 (Typ.)(CR≥10)(L/R/U/D) |
| maiztasuna | 60Hz |
| lanpara mota | 2 pcsCCFL |
| seinale interfazea | LVDS (1 ch, 8-bit) |
| sarrerako tentsioa | 3.3V (Typ.) |
| aplikazio | DMPC |
