| PartZenbakia | LM171WX3-TLC2 |
| Marka | LG Display |
| Tamaina | 17.1 |
| Aplikazio | DMPC |
| Ebazpena | 1440×900 |
| Konposizioa | LCM |
| Distira | 250 |
| CR | 800:1 |
| Koloreak | 16.7M |
| Atzeko argia | CCFL |
| Interfazea | LVDS |
| panel marka | LG Display |
| panel eredua | LM171WX3-TLC2 4 Compatible model |
| panel mota | a-Si TFT-LCD , LCM |
| panelaren tamaina | 17.1 inch |
| ebazpena | 1440(RGB)×900 , WXGA+ |
| bistaratzeko modua | TN, Normally White, Transmissive |
| eremu aktiboa | 367.2×229.5 mm |
| eskema | 389.2×254.5×12 mm |
| azalera | Antiglare (Haze 12%), Hard coating (3H) |
| distira | 250 cd/m² (Typ.) |
| kontraste-erlazioa | 800:1 (Typ.) |
| bistaratzeko koloreak | 16.7M (6-bit + Hi-FRC), CIE193160% |
| erantzun denbora | 2/6 (Typ.)(Tr/Td) |
| ikuspegi angelua | 85/85/65/85 (Typ.)(CR≥10)(L/R/U/D) |
| maiztasuna | 60Hz |
| lanpara mota | 2 pcsCCFLWithout Driver |
| seinale interfazea | LVDS (2 ch, 8-bit), 30 pins |
| sarrerako tentsioa | 5.0V (Typ.) |
| aplikazio | DMPC |
| LM171W02-TLB2 | LG Display | 17.1 | 1440×900 |
| LM171WX3-TLA1 | LG Display | 17.1 | 1440×900 |
| LM171WX3-TLB2 | LG Display | 17.1 | 1440×900 |
| LM171WX3-TLC1 | LG Display | 17.1 | 1440×900 |
| LM171WX3-TLC2 | LG Display | 17.1 | 1440×900 |
| LP171WE2-TLA2 | LG Display | 17.1 | 1680×1050 |
| LP171WP4-TLB3 | LG Display | 17.1 | 1440×900 |
| LP171WU5-TLA1 | LG Display | 17.1 | 1920×1200 |
| LP171WU6-TLB1 | LG Display | 17.1 | 1920×1200 |
| LP171WX2-TLA2 | LG Display | 17.1 | 1440×900 |
| HT190WG3-100 | BOE | 19.0 | 1440×900 |
| LM190E08-TLJ8 | LG Display | 19.0 | 1280×1024 |
| LM230WF3-SLL1 | LG Display | 23.0 | 1920×1080 |
| LM230WF5-TLF4 | LG Display | 23.0 | 1920×1080 |
| LM238WF2-SSK1 | LG Display | 23.8 | 1920×1080 |
| LM270WQ1-SLB1 | LG Display | 27.0 | 2560×1440 |
| LTM170EU-A01 | Samsung | 17.0 | 1280×1024 |
| LTM270HL02 | Samsung | 27.0 | 1920×1080 |
| M215HGE-L21 | Innolux | 21.5 | 1920×1080 |
| M236H1-L07 | Innolux | 23.6 | 1920×1080 |
