| PartZenbakia | TM084SDHG50 |
| Marka | Tianma |
| Tamaina | 8.4 |
| Aplikazio | IA |
| Ebazpena | 800×600 |
| Konposizioa | LCM |
| Distira | |
| CR | 500:1 |
| Koloreak | 262K/16.7M |
| Atzeko argia | WLED |
| Interfazea | LVDS |
| panel marka | TIANMA |
| panel eredua | TM084SDHG50 |
| panel mota | a-Si TFT-LCD , LCM |
| panelaren tamaina | 8.4 inch |
| ebazpena | 800(RGB)×600 , SVGA |
| bistaratzeko modua | TN, Normally White, Transmissive |
| eremu aktiboa | 170.4×127.8 mm |
| azalera | |
| distira | |
| kontraste-erlazioa | 500:1 (Typ.) |
| bistaratzeko koloreak | 262K/16.7M (6-bit / 6-bit + Hi-FRC), CIE193150% |
| erantzun denbora | 20 (Typ.)(Tr+Td) |
| ikuspegi angelua | 70/70/60/70 (Typ.)(CR≥10)(L/R/U/D) |
| lanpara mota | WLED |
| seinale interfazea | LVDS (1 ch, 6/8-bit), 20 pins |
| sarrerako tentsioa | 3.3V (Typ.) |
| aplikazio | IA |
| AA084SB01 | Mitsubishi | 8.4 | 800×600 |
| AA084SC01 | Mitsubishi | 8.4 | 800×600 |
| AA084SD11 | Mitsubishi | 8.4 | 800×600 |
| LB084S02-TD01 | LG Display | 8.4 | 800×600 |
| LTA084C274F | TOSHIBA | 8.4 | 800×600 |
| TM084SBHG04 | Tianma | 8.4 | 800×600 |
| TM084SDHG01 | Tianma | 8.4 | 800×600 |
| TM084SDHG02 | Tianma | 8.4 | 800×600 |
| TM084SDHG03 | Tianma | 8.4 | 800×600 |
| TM084SDHG50 | Tianma | 8.4 | 800×600 |
| AA150XN01 | Mitsubishi | 15.0 | 1024×768 |
| EL320.240.36 ET CC | Lumineq | 5.7 | 320×240 |
| G085VW01 V1 | AUO | 8.5 | 800×480 |
| G150XG02 V0 | AUO | 15.0 | 1024×768 |
| G156BGE-L01 | Innolux | 15.6 | 1366×768 |
| LQ084V1DG22 | SHARP | 8.4 | 640×480 |
| OEL9M0065-R-E | Other | 2.7 | 256×64 |
| PD104SL5 | E Ink | 10.4 | 800×600 |
| TX31D37VM0CAA | KOE | 12.1 | 800×600 |
| UG-2864HMBEG01 | WiseChip | 0.96 | 128×64 |
