| PartZenbakia | TM062RDH03 |
| Marka | Tianma |
| Tamaina | 6.2 |
| Aplikazio | CNS |
| Ebazpena | 800×480 |
| Konposizioa | LCM |
| Distira | 400 |
| CR | 500:1 |
| Koloreak | 262K/16.7M |
| Atzeko argia | WLED |
| Interfazea | TTL |
| panel marka | TIANMA |
| panel eredua | TM062RDH03 |
| panel mota | a-Si TFT-LCD , LCM |
| panelaren tamaina | 6.2 inch |
| ebazpena | 800(RGB)×480 , WVGA |
| bistaratzeko modua | TN, Normally White, Transmissive |
| eremu aktiboa | 137.4×77.28 mm |
| eskema | 155.2×88.2×5.2 mm |
| azalera | Antiglare |
| distira | 400 cd/m² (Typ.) |
| kontraste-erlazioa | 500:1 (Typ.) |
| bistaratzeko koloreak | 262K/16.7M (6-bit / 6-bit + Dithering), CIE193147% |
| erantzun denbora | 20 (Typ.)(Tr+Td) |
| ikuspegi angelua | 75/75/60/70 (Typ.)(CR≥10)(L/R/U/D) |
| lanpara mota | 3S8PWLEDWithout Driver |
| seinale interfazea | TTL (1 ch, 8-bit), 60 pins |
| sarrerako tentsioa | 3.3/9.84/19/-7V (Typ.)(AVCC/DVCC/VGH/VGL) |
| aplikazio | CNS |
| AT062TN12 | Innolux | 6.2 | |
| HSD062IDW1-A00 | HannStar | 6.2 | 800×480 |
| PM062HT1 | E Ink | 6.2 | 640×240 |
| PW062XS6 | E Ink | 6.2 | 480×234 |
| PW062XU8 | E Ink | 6.2 | 480×234 |
| TM062RDH03 | Tianma | 6.2 | 800×480 |
| TM062RDS01 | Tianma | 6.2 | 800×480 |
| TM062RDZG10 | Tianma | 6.2 | 800×480 |
| TX16D11VM2CCA | KOE | 6.2 | 640×240 |
| A070FW03 V7 | AUO | 7.0 | 480×234 |
| CLAA069LA0FCW | CPT | 7.0 | 800×480 |
| DJ080PA-01C | Innolux | 8.0 | |
| GCX123AKQ-E | JDI | 3.5 | 240×320 |
| HSD040I3N1-B00 | HannStar | 4.0 | 320×240 |
| HT07W12-200 | HYDIS | 7.0 | 480×234 |
| LQ070Y5DG12 | SHARP | 7.0 | 800×480 |
| M090SWP1 R0 | IVO | 9.0 | 800×480 |
| PM061WX1 | E Ink | 6.1 | 800×480 |
| PW080XU1 | E Ink | 8.0 | 480×220 |
