| PartZenbakia | TM028HDZ58 |
| Marka | TIANMA |
| Tamaina | 2.8 |
| Aplikazio | Mobile Phone |
| Ebazpena | 240×320 |
| Konposizioa | LCM, a-Si TFT-LCD |
| Distira | |
| CR | 500:1 |
| Koloreak | 65K/262K |
| Atzeko argia | 1S4P |
| Interfazea | Parallel |
| fabrikatzailea | TIANMA |
| ereduaren izena | TM028HDZ58 |
| pantailaren tamaina | 2.8 inch |
| pantaila mota | LCM, a-Si TFT-LCD |
| pixel-zenbakia | 240(RGB)×320 (QVGA) 141PPI |
| antolamendua | RGB Vertical Stripe |
| eremu aktiboa (mm) | 43.2 × 57.6 (H×V) |
| eskema (mm) | - |
| luminantzia | - |
| kontraste-erlazioa | 500 : 1 (Typ.) (TM) |
| ikuspegi angelua | 60/60/60/50 (Typ.)(CR≥10) |
| erantzuna | 25 (Typ.)(Tr+Td) ms |
| ikuspegi ona | 6 o'clock |
| lan egiteko modua | TN, Normally White, Transmissive |
| kolore-sakonera | 65K/262K 55% NTSC |
| atzeko argia | 1S4P WLED , No Driver |
| masa | - |
| erabiltzen | Mobile Phone |
| freskatze tasa | 60Hz |
| pantaila taktila | Without |
| seinale mota | Parallel RGB (1 ch, 6-bit) + SPI |
| gehienez. balorazioak | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
| 28QVF1H | SII | 2.8 | 240×320 |
| ET028002DHU | EDT | 2.8 | 240×320 |
| LMS283GF11 | Samsung | 2.8 | 240×320 |
| LS028B8PX05 | SHARP | 2.8 | 240×400 |
| LTE283QV-F01 | Samsung | 2.8 | 320×240 |
| LTP283QV-F04 | Samsung | 2.8 | 240×320 |
| TM028HBHG02 | Tianma | 2.8 | 240×320 |
| TM028HDH21 | Tianma | 2.8 | 240×320 |
| TM028LDH01 | Tianma | 2.8 | 240×400 |
| TM028LDZ09 | Tianma | 2.8 | 240×400 |
