| PartZenbakia | TCG085WVLCF-G00 |
| Marka | Kyocera |
| Tamaina | 8.5 |
| Aplikazio | Industrial |
| Ebazpena | 800×480 |
| Konposizioa | LCM , a-Si TFT-LCD |
| Distira | |
| CR | 500:1 |
| Koloreak | 262K |
| Atzeko argia | WLED |
| Interfazea | Parallel |
| fabrikatzailea | Kyocera |
| ereduaren izena | TCG085WVLCF-G00 |
| pantailaren tamaina | 8.5 inch |
| pantaila mota | LCM , a-Si TFT-LCD |
| pixel-zenbakia | 800(RGB)×480 (WVGA) 109PPI |
| antolamendua | RGB Vertical Stripe |
| eremu aktiboa (mm) | 184.8 × 110.88 (H×V) |
| eskema (mm) | 210 × 134 × 11.1 (H×V×D) |
| bezela eremua (mm) | - |
| tratamendua | Antiglare |
| luminantzia | 320 cd/m² (Typ.) |
| kontraste-erlazioa | 500 : 1 (Typ.) (TM) |
| ikuspegi angelua | 60/60/60/45 (Typ.)(CR≥10) |
| erantzuna | 15/35 (Typ.)(Tr/Td) ms |
| ikuspegi ona | - |
| lan egiteko modua | TN, Normally White, Transmissive |
| kolore-sakonera | 262K 49% NTSC |
| atzeko argia | WLED , 50K hours , No Driver |
| masa | TBD |
| erabiltzen | Industrial |
| freskatze tasa | 60Hz |
| pantaila taktila | 4-wire Resistive Touch, G/G |
| seinale mota | Parallel RGB (1 ch, 6-bit) , 40 pins Connector |
| tentsio-hornidura | 3.3V (Typ.) |
| gehienez. balorazioak | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
