| PartZenbakia | S101WS07 |
| Marka | CDTECH |
| Tamaina | 10.1 |
| Aplikazio | Industrial |
| Ebazpena | 1024×600 |
| Konposizioa | LCM , a-Si TFT-LCD |
| Distira | |
| CR | 600:1 |
| Koloreak | 16.7M |
| Atzeko argia | 3S6P |
| Interfazea | Parallel |
| fabrikatzailea | CDTECH |
| pantailaren tamaina | 10.1 inch |
| pixel-zenbakia | 1024(RGB)×600 (WSVGA) 117PPI |
| eremu aktiboa (mm) | 222.72 × 125.28 (H×V) |
| bezela eremua (mm) | 226.34 × 128.1 (H×V) |
| luminantzia | 200 cd/m² (Typ.) |
| ikuspegi angelua | 65/65/55/65 (Typ.)(CR≥10) |
| ikuspegi ona | 12 o'clock |
| kolore-sakonera | 16.7M |
| masa | TBD |
| freskatze tasa | 60Hz |
| seinale mota | Parallel RGB (1 ch, 8-bit) , 50 pins FPC |
| tentsio-hornidura | 3.3/10.85/21/-5.5V (Typ.)(DVDD/AVDD/VGH/VGL) |
| gehienez. balorazioak | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
| ereduaren izena | S101WS07 |
| pantaila mota | LCM , a-Si TFT-LCD |
| antolamendua | RGB Vertical Stripe |
| eskema (mm) | 235 × 143 × 5.39 (H×V×D) |
| tratamendua | - |
| kontraste-erlazioa | 600 : 1 (Typ.) (TM) |
| erantzuna | 6/20 (Typ.)(Tr/Td) ms |
| lan egiteko modua | TN, Normally White, Transmissive |
| atzeko argia | 3S6P WLED , 25K hours , No Driver |
| erabiltzen | Industrial |
| pantaila taktila | Without |
