| PartZenbakia | NL8060AC26-11 |
| Marka | NLT |
| Tamaina | 10.4 |
| Aplikazio | IA |
| Ebazpena | 800×600 |
| Konposizioa | LCM |
| Distira | 190 |
| CR | 150:1 |
| Koloreak | 262K |
| Atzeko argia | CCFL |
| Interfazea | TTL |
| panel marka | NEC |
| panel eredua | NL8060AC26-11 |
| panel mota | a-Si TFT-LCD , LCM |
| panelaren tamaina | 10.4 inch |
| ebazpena | 800(RGB)×600 , SVGA |
| bistaratzeko modua | TN, Normally White, Transmissive |
| eremu aktiboa | 211.2×158.4 mm |
| eskema | 243×185.1 mm |
| azalera | |
| distira | 190 cd/m² (Typ.) |
| kontraste-erlazioa | 150:1 (Typ.) |
| bistaratzeko koloreak | 262K (6-bit), CIE193142% |
| erantzun denbora | 40 (Max.)(Tr) |
| ikuspegi angelua | 45/45/20/45 (Typ.)(CR≥10)(L/R/U/D) |
| maiztasuna | 60Hz |
| lanpara mota | 1 pcsCCFLEmbedded (Inverter) |
| seinale interfazea | CMOS (1 ch, 6-bit), 41 pins |
| sarrerako tentsioa | 3.3/5.0V (Typ.)(VCC) |
| aplikazio | IA |
| NL8060AC26-11 | NLT | 10.4 | 800×600 |
| NL8060BC21-03 | NLT | 8.4 | 800×600 |
| NL8060BC21-11F | NLT | 8.4 | 800×600 |
| NL8060BC26-11 | NLT | 10.4 | 800×600 |
| NL8060BC26-27 | NLT | 10.4 | 800×600 |
| NL8060BC26-28 | NLT | 10.4 | 800×600 |
| NL8060BC31-02 | NLT | 12.1 | 800×600 |
| NL8060BC31-20 | NLT | 12.1 | 800×600 |
| NL8060BC31-27 | NLT | 12.1 | 800×600 |
| NL8060BC31-27D | NLT | 12.1 | 800×600 |
| AA121SL09 | Mitsubishi | 12.1 | 800×600 |
| EW24B00GLY | EDT | 5.2 | 240×64 |
| LM24014H | SHARP | 5.2 | 240×64 |
| LMG5278XUFC-00T | KOE | 9.4 | 640×480 |
| LQ121S1LG41 | SHARP | 12.1 | 800×600 |
| LTA057A340F | TOSHIBA | 5.7 | 320×240 |
| LTA104A261F | TOSHIBA | 10.4 | 640×480 |
| NL6448BC18-06F | NLT | 5.7 | 640×480 |
| SX19V007-Z2A | KOE | 7.5 | 640×480 |
| UG-2864ASYIG01 | WiseChip | 2.7 | 128×64 |
