| PartZenbakia | NL13676BC25-07F |
| Marka | NLT |
| Tamaina | 15.6 |
| Aplikazio | Industrial Outdoor H |
| Ebazpena | 1366×768 |
| Konposizioa | a-Si TFT-LCD , LCM |
| Distira | |
| CR | 900:1 |
| Koloreak | 262K/16.7M |
| Atzeko argia | 6 |
| Interfazea | LVDS |
| panel marka | NLT |
| panelaren tamaina | 15.6" |
| ebazpena | 1366(RGB)×768, WXGA, 100PPI |
| bistaratzeko eremua | 344.232(W)×193.536(H) mm |
| eskema tamaina | 363.8(W)×215.9(H) ×13.15(D) mm |
| distira | 1250 cd/m² (Typ.) |
| ikuspegi angelua | 80/80/80/80 (Typ.)(CR≥10) |
| ikuspegirik onena | 6 o'clock |
| bistaratzeko koloreak | 262K/16.7M 60% NTSC |
| maiztasuna | 60Hz |
| panelaren pisua | 1.07/1.17Kgs (Typ./Max.) |
| seinale interfazea | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| sarrerako tentsioa | 3.3V (Typ.) |
| ingurunea | Operating Temp.: -30 ~ 80 °C ; Storage Temp.: -30 ~ 80 °C |
| panel eredua | NL13676BC25-07F |
| panel mota | a-Si TFT-LCD , LCM |
| pixel formatua | RGB Vertical Stripe |
| bezela irekidura | 347.55(W)×196.85(H) mm |
| azalera | Antiglare, Hard coating (3H) |
| kontraste-erlazioa | 900:1 (Typ.) (TM) |
| bistaratzeko modua | TN, Normally White, Transmissive |
| erantzun denbora | 3/15 (Typ.)(Tr/Td) |
| lanpara mota | 6 strings WLED , 7K hours , Without Driver |
| pantaila taktila | Without |
| aplikazio | Industrial Outdoor High Brightness |
