| PartZenbakia | N156HGE-EA2 |
| Marka | Innolux |
| Tamaina | 15.6 |
| Aplikazio | NBPC |
| Ebazpena | 1920×1080 |
| Konposizioa | LCM |
| Distira | 300 |
| CR | 500:1 |
| Koloreak | 262K |
| Atzeko argia | WLED |
| Interfazea | eDP |
| panel marka | INNOLUX |
| panel eredua | N156HGE-EA2 12 Compatible model |
| panel mota | a-Si TFT-LCD , LCM |
| panelaren tamaina | 15.6 inch |
| ebazpena | 1920(RGB)×1080 , FHD |
| bistaratzeko modua | TN, Normally White, Transmissive |
| eremu aktiboa | 344.16×193.59 mm |
| eskema | 359.5×223.8×3.2 mm |
| forma estiloa | Slim (PCBA Flat, Depth ≤3.2mm) |
| azalera | Antiglare (Haze 24%), Hard coating (3H) |
| distira | 300 cd/m² (Typ.) |
| kontraste-erlazioa | 500:1 (Typ.) |
| bistaratzeko koloreak | 262K (6-bit), CIE193160% |
| erantzun denbora | 3/8 (Typ.)(Tr/Td) |
| ikuspegi angelua | 45/45/20/45 (Typ.)(CR≥10)(L/R/U/D) |
| maiztasuna | 60Hz |
| lanpara mota | WLEDEmbedded (LED Driver) |
| seinale interfazea | eDP (2 Lanes), 30 pins |
| sarrerako tentsioa | 3.3V (Typ.) |
| aplikazio | NBPC |
| LP156WF3-SLB2 | LG Display | 15.6 | 1920×1080 |
| LTN156KT02-301 | Samsung | 15.6 | 1600×900 |
| N156HCA-EA1 | Innolux | 15.6 | 1920×1080 |
| N156HGE-EA1 | Innolux | 15.6 | 1920×1080 |
| N156HGE-EA2 | Innolux | 15.6 | 1920×1080 |
| N156HGE-EAL Rev.C1 | Innolux | 15.6 | 1920×1080 |
| N156HGE-L11 | Innolux | 15.6 | 1920×1080 |
| N156HGE-LA1 | Innolux | 15.6 | 1920×1080 |
| N156HGE-LB1 | Innolux | 15.6 | 1920×1080 |
| N156HGE-LG1 | Innolux | 15.6 | 1920×1080 |
| B101XTN01.1 | AUO | 10.1 | 1366×768 |
| B125HAN02.2 | AUO | 12.5 | 1920×1080 |
| B154PW02 V1 | AUO | 15.4 | 1440×900 |
| LP101WH1-TLB2 | LG Display | 10.1 | 1366×768 |
| LP154WX4-TLC3 | LG Display | 15.4 | 1280×800 |
| LTM12C278F | TOSHIBA | 12.1 | 800×600 |
| LTN133AT03-001 | Samsung | 13.3 | 1280×800 |
| LTN156AT02-D02 | Samsung | 15.6 | 1366×768 |
| M133NWF2 R0 | IVO | 13.3 | 1920×1080 |
| N140BGE-LB2 | Innolux | 14.0 | 1366×768 |
