| PartZenbakia | M230HCJ-L3N Rev.C1 |
| Marka | Innolux |
| Tamaina | 23.0 |
| Aplikazio | Desktop Monitor |
| Ebazpena | 1920×1080 |
| Konposizioa | a-Si TFT-LCD, LCM |
| Distira | |
| CR | 1000:1 |
| Koloreak | 16.7M |
| Atzeko argia | 4 |
| Interfazea | LVDS |
| panel marka | Innolux |
| panel eredua | M230HCJ-L3N Rev.C1 |
| panelaren tamaina | 23.0" |
| panel mota | a-Si TFT-LCD, LCM |
| ebazpena | 1920(RGB)×1080, FHD, 95PPI |
| pixel formatua | RGB Vertical Stripe |
| bistaratzeko eremua | 509.184(W)×286.416(H) mm |
| bezela irekidura | 512.38(W)×289.62(H) mm |
| eskema tamaina | 522.38(W)×305.62(H) mm |
| azalera | Antiglare (Haze 25%), Hard coating (3H) |
| distira | 250 cd/m² (Typ.) |
| kontraste-erlazioa | 1000:1 (Typ.) (TM) |
| ikuspegi angelua | 89/89/89/89 (Typ.)(CR≥10) |
| bistaratzeko modua | AAS, Normally Black, Transmissive |
| ikuspegirik onena | Symmetry |
| erantzun denbora | 8/7 (Typ.)(Tr/Td) |
| bistaratzeko koloreak | 16.7M 72% NTSC |
| lanpara mota | 4 strings WLED , Without Driver |
| maiztasuna | 60Hz |
| pantaila taktila | Without |
| panelaren pisua | 1.96/2.06/2.23Kgs (Min./Typ./Max.) |
| aplikazio | Desktop Monitor |
| seinale interfazea | LVDS (2 ch, 8-bit) , 30 pins Connector |
| sarrerako tentsioa | 5.0V (Typ.) |
| ingurunea | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
