| PartZenbakia | M220Z1-P03 |
| Marka | Innolux |
| Tamaina | 22.0 |
| Aplikazio | DMPC |
| Ebazpena | 1680×1050 |
| Konposizioa | CELL |
| Distira | 0 |
| CR | 1000:1 |
| Koloreak | 16.7M |
| Atzeko argia | No B/L |
| Interfazea | LVDS |
| panel marka | CMO |
| panel eredua | M220Z1-P03 |
| panel mota | a-Si TFT-LCD , CELL |
| panelaren tamaina | 22.0 inch |
| ebazpena | 1680(RGB)×1050 , WSXGA+ |
| bistaratzeko modua | TN, Normally White, Transmissive |
| eremu aktiboa | 473.76×296.1 mm |
| eskema | 485.26×307.6 mm |
| azalera | Antiglare (Haze 25%), Hard coating (3H) |
| beiraren sakonera | 0.70+0.70 mm |
| transmisibitatea | 5.8% (Typ.)(with Polarizer) |
| kontraste-erlazioa | 1000:1 (Typ.) |
| bistaratzeko koloreak | 16.7M (8-bit) |
| erantzun denbora | 1.3/3.7 (Typ.)(Tr/Td) |
| ikuspegi angelua | 85/85/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| maiztasuna | 60Hz |
| seinale interfazea | LVDS (2 ch, 8-bit), 30 pins |
| sarrerako tentsioa | 5.0V (Typ.) |
| aplikazio | DMPC |
