| PartZenbakia | M220Z1-L05 |
| Marka | Innolux |
| Tamaina | 22.0 |
| Aplikazio | DMPC |
| Ebazpena | 1680×1050 |
| Konposizioa | LCM |
| Distira | 300 |
| CR | 1000:1 |
| Koloreak | 16.7M |
| Atzeko argia | CCFL |
| Interfazea | LVDS |
| panel marka | CMO |
| panel eredua | M220Z1-L05 |
| panel mota | a-Si TFT-LCD , LCM |
| panelaren tamaina | 22.0 inch |
| ebazpena | 1680(RGB)×1050 , WSXGA+ |
| bistaratzeko modua | TN, Normally White, Transmissive |
| eremu aktiboa | 473.76×296.1 mm |
| eskema | 493.7×320.1 mm |
| azalera | Antiglare (Haze 25%), Hard coating (3H) |
| distira | 300 cd/m² (Typ.) |
| kontraste-erlazioa | 1000:1 (Typ.) |
| bistaratzeko koloreak | 16.7M (6-bit + Hi-FRC), CIE193192% |
| erantzun denbora | 1.3/3.7 (Typ.)(Tr/Td) |
| ikuspegi angelua | 85/85/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| maiztasuna | 60Hz |
| lanpara mota | 4 pcsCCFLWithout Driver |
| seinale interfazea | LVDS (2 ch, 8-bit), 30 pins |
| sarrerako tentsioa | 5.0V (Typ.) |
| aplikazio | DMPC |
| LM220WE1-TLB3 | LG Display | 22.0 | 1680×1050 |
| LM220WE1-TLD2 | LG Display | 22.0 | 1680×1050 |
| M220Z1-L01 | Innolux | 22.0 | 1680×1050 |
| M220Z1-L03 | Innolux | 22.0 | 1680×1050 |
| M220Z1-L05 | Innolux | 22.0 | 1680×1050 |
| M220Z1-L09 | Innolux | 22.0 | 1680×1050 |
| M220Z1-L0A | Innolux | 22.0 | 1680×1050 |
| M220Z1-P03 | Innolux | 22.0 | 1680×1050 |
| M220Z3-LA3 | Innolux | 22.0 | 1680×1050 |
| M220ZGE-L20 | Innolux | 22.0 | 1680×1050 |
| LM201U04-A3K6 | LG Display | 20.1 | 1600×1200 |
| LM240WU5-SLA1 | LG Display | 24.0 | 1920×1200 |
| LM340UW2-SSA1 | LG Display | 34 | 3440×1440 |
| LTM190EX-L21 | Samsung | 19.0 | 1280×1024 |
| M170EP01 V2 | AUO | 17.0 | 1280×1024 |
| M185XTN01.2 | AUO | 18.5 | 1366×768 |
| M185XW01 VF | AUO | 18.5 | 1366×768 |
| M270HW01 V0 | AUO | 27.0 | 1920×1080 |
| MT185WHM-N10 | BOE | 18.5 | 1366×768 |
| TX38D14VC0CAA | KOE | 15.0 | 1024×768 |
