| PartZenbakia | M170XW01 V3 |
| Marka | AUO |
| Tamaina | 17.0 |
| Aplikazio | DMPC |
| Ebazpena | 1280×768 |
| Konposizioa | LCM |
| Distira | 450 |
| CR | 800:1 |
| Koloreak | 16.2M |
| Atzeko argia | CCFL |
| Interfazea | LVDS |
| panel marka | AUO |
| panel eredua | M170XW01 V3 1 Compatible model |
| panel mota | a-Si TFT-LCD , LCM |
| panelaren tamaina | 17.0 inch |
| ebazpena | 1280(RGB)×768 , WXGA |
| bistaratzeko modua | MVA, Normally Black, Transmissive |
| eremu aktiboa | 370.56×222.336 mm |
| eskema | 404×248.5×17.8 mm |
| azalera | Glare (Haze 0%), Hard coating (2H) |
| distira | 450 cd/m² (Typ.) |
| kontraste-erlazioa | 800:1 (Typ.) |
| bistaratzeko koloreak | 16.2M (6-bit + FRC) |
| erantzun denbora | 15/10 (Typ.)(Tr/Td) |
| ikuspegi angelua | 85/85/85/85 (Typ.)(CR＞10)(L/R/U/D) |
| maiztasuna | 60Hz |
| lanpara mota | 4 pcsCCFLWithout Driver |
| seinale interfazea | LVDS (1 ch, 8-bit), 20 pins |
| sarrerako tentsioa | 5.0V (Typ.) |
| aplikazio | DMPC |
