LTN121AT11-803

LTN121AT11-803
LTN121AT11-803
LTN121AT11-803 thumb LTN121AT11-803 thumb
Marka
Samsung
Tamaina
12.1
Aplikazio
NBPC
Ebazpena
1280×800
Konposizioa
LCM
Distira
300
CR
300:1
Koloreak
262K
Atzeko argia
WLED
Interfazea
LVDS
In Stock
500
Zehaztapenak

PartZenbakia LTN121AT11-803
MarkaSamsung
Tamaina12.1
AplikazioNBPC
Ebazpena1280×800
KonposizioaLCM
Distira300
CR300:1
Koloreak262K
Atzeko argiaWLED
InterfazeaLVDS
panel markaSAMSUNG
panel ereduaLTN121AT11-803
panel mota a-Si TFT-LCD , LCM
panelaren tamaina12.1 inch
ebazpena1280(RGB)×800 , WXGA
bistaratzeko moduaTN, Normally White, Transmissive
eremu aktiboa261.12×163.2 mm
eskema274.5×177.5×3.6 mm
azaleraHard coating (3H)
distira300 cd/m² (Typ.)
kontraste-erlazioa300:1 (Min.)
bistaratzeko koloreak262K (6-bit), CIE193145%
erantzun denbora16 (Typ.)(Tr+Td)
ikuspegi angelua45/45/20/30 (Min.)(CR≥10)(L/R/U/D)
maiztasuna60Hz
lanpara mota6S4PWLEDEmbedded (LED Driver)
seinale interfazeaLVDS (1 ch, 6-bit), 40 pins
sarrerako tentsioa3.3V (Typ.)
aplikazioNBPC
