| PartZenbakia | LQ150X1DWF1 |
| Marka | SHARP |
| Tamaina | 15.0 |
| Aplikazio | DMPC |
| Ebazpena | 1024×768 |
| Konposizioa | LCM |
| Distira | 250 |
| CR | 400:1 |
| Koloreak | 262K |
| Atzeko argia | CCFL |
| Interfazea | TTL |
| panel marka | SHARP |
| panel eredua | LQ150X1DWF1 1 Compatible model |
| panel mota | a-Si TFT-LCD , LCM |
| panelaren tamaina | 15.0 inch |
| ebazpena | 1024(RGB)×768 , XGA |
| bistaratzeko modua | MVA, Normally Black, Transmissive |
| eremu aktiboa | 304.128×228.096 mm |
| eskema | 347.3×263.5×16.8 mm |
| azalera | Antiglare (Haze 25%), Hard coating (2H) |
| distira | 250 cd/m² (Typ.) |
| kontraste-erlazioa | 400:1 (Typ.) |
| bistaratzeko koloreak | 262K (6-bit) |
| erantzun denbora | 15/10 (Typ.)(Tr/Td) |
| ikuspegi angelua | 80/80/80/80 (Min.)(CR≥10)(L/R/U/D) |
| maiztasuna | 60Hz |
| lanpara mota | 4 pcsCCFLWithout Driver |
| seinale interfazea | CMOS/TTL (2 ch, 6-bit), 60 pins |
| sarrerako tentsioa | 5.0V (Typ.)(VCC) |
| aplikazio | DMPC |
