| PartZenbakia | HSD070PFW1-A00 |
| Marka | HannStar |
| Tamaina | 7.0 |
| Aplikazio | NOPC |
| Ebazpena | 1024×600 |
| Konposizioa | LCM |
| Distira | 450 |
| CR | 800:1 |
| Koloreak | 16.7M |
| Atzeko argia | WLED |
| Interfazea | LVDS |
| panel marka | HannStar |
| panel eredua | HSD070PFW1-A00 |
| panel mota | a-Si TFT-LCD , LCM |
| panelaren tamaina | 7.0 inch |
| ebazpena | 1024(RGB)×600 , WSVGA |
| bistaratzeko modua | TN, Normally White, Transmissive |
| eremu aktiboa | 153.6×90 mm |
| eskema | 164.05×100.86×4.94 mm |
| azalera | Glare (Haze 0%), Hard coating, Reflection 1.5% (Max.) |
| distira | 450 cd/m² (Typ.) |
| kontraste-erlazioa | 800:1 (Typ.) |
| bistaratzeko koloreak | 16.7M (6-bit + Hi-FRC), CIE193150% |
| erantzun denbora | 4/12 (Typ.)(Tr/Td) |
| ikuspegi angelua | 80/80/80/70 (Typ.)(CR≥10)(L/R/U/D) |
| maiztasuna | 60Hz |
| lanpara mota | 3S7PWLEDEmbedded (LED Driver) |
| seinale interfazea | LVDS (1 ch, 8-bit), 31 pins |
| sarrerako tentsioa | 3.2/4.2V (Min./Max.) |
| aplikazio | NOPC |
