| PartZenbakia | LM171WX3-TLA1 |
| Marka | LG Display |
| Tamaina | 17.1 |
| Aplikazio | DMPC |
| Ebazpena | 1440×900 |
| Konposizioa | LCM |
| Distira | 250 |
| CR | 800:1 |
| Koloreak | 16.7M |
| Atzeko argia | CCFL |
| Interfazea | LVDS |
| panel marka | LG.Philips LCD |
| panel eredua | LM171WX3-TLA1 4 Compatible model |
| panel mota | a-Si TFT-LCD , LCM |
| panelaren tamaina | 17.1 inch |
| ebazpena | 1440(RGB)×900 , WXGA+ |
| bistaratzeko modua | TN, Normally White, Transmissive |
| eremu aktiboa | 367.2×229.5 mm |
| eskema | 389.2×254.5×12 mm |
| azalera | Antiglare (Haze 12%), Hard coating (3H) |
| distira | 250 cd/m² (Typ.) |
| kontraste-erlazioa | 800:1 (Typ.) |
| bistaratzeko koloreak | 16.7M (6-bit + Hi-FRC), CIE193160% |
| erantzun denbora | 2/6 (Typ.)(Tr/Td) |
| ikuspegi angelua | 80/80/75/85 (Typ.)(CR≥10)(L/R/U/D) |
| maiztasuna | 60Hz |
| lanpara mota | 2 pcsCCFLWithout Driver |
| seinale interfazea | LVDS (2 ch, 8-bit), 30 pins |
| sarrerako tentsioa | 5.0V (Typ.) |
| aplikazio | DMPC |
