| PartZenbakia | LM156LF6L01 |
| Marka | PANDA |
| Tamaina | 15.6 |
| Aplikazio | Laptop |
| Ebazpena | 1920×1080 |
| Konposizioa | Oxide TFT-LCD , LCM |
| Distira | |
| CR | 1000:1 |
| Koloreak | 262K |
| Atzeko argia | WLED |
| Interfazea | eDP |
| marka | PANDA |
| diagonalaren tamaina | 15.6 inch |
| pixel formatua | 1920(RGB)×1080 [FHD] 141PPI |
| eremu aktiboa | 344.16(H)×193.59(V) mm |
| bezela eremua | - |
| luminantzia | 250 cd/m² (Typ.) |
| ikusi norabidea | Symmetry |
| ikuspegi angelua | 85/85/85/85 (Typ.)(CR≥10) |
| euskarria kolorea | 262K 45% NTSC |
| forma estiloa | Slim (PCBA Flat, T≤3.2mm) |
| fotograma-tasa | 60Hz |
| interfaze mota | eDP (2 Lanes) , eDP1.2 , HBR1 (2.7G/lane) , 30 pins Connector |
| energia hornidura | 3.3V (Typ.) |
| ingurunea | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
| eredua | LM156LF6L01 (NCP0025) 2 Compatible |
| mota | Oxide TFT-LCD , LCM |
| konfigurazioa | RGB Vertical Stripe |
| eskema dim. | 359.5(H)×223.8(V) ×3.2(D) mm |
| tratamendua | Antiglare, Hard coating (3H) |
| kontraste-erlazioa | 1000:1 (Typ.) (TM) |
| erantzun denbora | 25 (Typ.)(Tr+Tf) |
| funtzionamendu modua | FFS, Normally Black, Transmissive |
| argi iturria | WLED , 15K hours , With LED Driver |
| entzat diseinatua | Laptop |
| ukipen-panela | Without |
