| PartZenbakia | LH570QH6-SD01 |
| Marka | LG Display |
| Tamaina | 5.7 |
| Aplikazio | Mobile Phone |
| Ebazpena | 1440×2880 |
| Konposizioa | Assembly , a-Si TF |
| Distira | |
| CR | 1500:1 |
| Koloreak | 16.7M |
| Atzeko argia | 4S3P |
| Interfazea | MIPI |
| fabrikatzailea | LG Display |
| pantailaren tamaina | 5.7 inch |
| pixel-zenbakia | 1440(RGB)×2880 564PPI |
| eremu aktiboa (mm) | 64.8 × 129.6 (H×V) |
| bezela eremua (mm) | - |
| luminantzia | 500 cd/m² (Typ.) |
| ikuspegi angelua | 80/80/80/80 (Typ.)(CR≥10) |
| ikuspegi ona | Symmetry |
| kolore-sakonera | 16.7M 85% NTSC |
| masa | 26.6±2.7g |
| freskatze tasa | 60Hz |
| seinale mota | MIPI (4 data lanes) , 54 pins Connector |
| tentsio-hornidura | 1.8/3.3/5.5/-5.5V (Typ.)(VDDI/VPNL/DDVDL/DDVDH) |
| gehienez. balorazioak | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
| ereduaren izena | LH570QH6-SD01 |
| pantaila mota | Assembly , a-Si TFT-LCD |
| antolamendua | RGB Vertical Stripe |
| eskema (mm) | 68.72 × 145.7 (H×V×D) |
| tratamendua | Hard coating |
| kontraste-erlazioa | 1500 : 1 (Typ.) (TM) |
| erantzuna | 25 (Typ.)(Tr+Td) ms |
| lan egiteko modua | - |
| atzeko argia | 4S3P WLED , No Driver |
| erabiltzen | Mobile Phone |
| pantaila taktila | PCAP |
