| PartZenbakia | LA102WH2-SL01 |
| Marka | LG Display |
| Tamaina | 10.2 |
| Aplikazio | Automotive Display |
| Ebazpena | 1280×720 |
| Konposizioa | LCM, a-Si TFT-LCD |
| Distira | |
| CR | 800:1 |
| Koloreak | 16.7M |
| Atzeko argia | 10S4P |
| Interfazea | LVDS |
| fabrikatzailea | LG Display |
| ereduaren izena | LA102WH2-SL01 |
| pantailaren tamaina | 10.2 inch |
| pantaila mota | LCM, a-Si TFT-LCD |
| pixel-zenbakia | 1280(RGB)×720 (WXGA) 143PPI |
| antolamendua | RGB Vertical Stripe |
| eremu aktiboa (mm) | 225.792 × 127.008 (H×V) |
| eskema (mm) | 238.62 × 141.5 (H×V×D) |
| bezela eremua (mm) | 225.75 × 126.874 (H×V) |
| tratamendua | Hard coating (3H) |
| luminantzia | 725 cd/m² (Min.) |
| kontraste-erlazioa | 800 : 1 (Min.) (TM) |
| ikuspegi angelua | 89/89/89/89 (Min.)(CR≥10) |
| erantzuna | 30 (Max.)(Tr+Td) ms |
| ikuspegi ona | Symmetry |
| lan egiteko modua | IPS, Normally Black, Transmissive |
| kolore-sakonera | 16.7M |
| atzeko argia | 10S4P WLED , 10K hours , No Driver |
| masa | 303/313g (Typ./Max.) |
| erabiltzen | Automotive Display |
| freskatze tasa | 60Hz |
| pantaila taktila | Without |
| seinale mota | LVDS (1 ch, 8-bit) , FPC 64 pins |
| tentsio-hornidura | 1.8/3.3/12.5/18.5/-7.5V (Typ.)(DVDD2/DVDD1/AVDD/VHG/VHL) |
| gehienez. balorazioak | Storage Temp.: -40 ~ 85 °C Operating Temp.: -40 ~ 85 °C ; Vibration Level: 3.16G (31.0 m/s²) |
| A102VW01 V7 | AUO | 10.2 | 800×480 |
| AT102TN03 V.3 | Innolux | 10.2 | 800×480 |
| CLAA102NA01CW | CPT | 10.2 | 1024×600 |
| CLAA102NA0ACG | CPT | 10.2 | 1024×600 |
| CLAA102NA0DCW | CPT | 10.2 | 1024×600 |
| CLAA102NB01XV | CPT | 10.2 | 1024×600 |
| EZ102AS181 | PDI | 10.2 | 1024×1280 |
| EZ102AT011 | PDI | 10.2 | 1024×1280 |
| PM102WX1 | E Ink | 10.2 | 800×480 |
| PM102ZY2 | E Ink | 10.2 | 1024×600 |
