| PartZenbakia | HV550QUB-F12 |
| Marka | BOE |
| Tamaina | 55 |
| Aplikazio | TV Sets |
| Ebazpena | 3840×2160 |
| Konposizioa | a-Si TFT-LCD, CELL |
| Distira | |
| CR | 1200:1 |
| Koloreak | 1.07B |
| Atzeko argia | No |
| Interfazea | V-by-One |
| panel marka | BOE |
| panel eredua | HV550QUB-F12 |
| panelaren tamaina | 55" |
| panel mota | a-Si TFT-LCD, CELL |
| ebazpena | 3840(RGB)×2160, UHD, 80PPI |
| pixel formatua | RGB Vertical Stripe |
| bistaratzeko eremua | 1209.6(W)×680.4(H) mm |
| bezela irekidura | - |
| eskema tamaina | 1221.4(W)×694.8(H) ×1.34(D) mm |
| azalera | Antiglare (Haze 1%), Hard coating (3H) |
| distira | 0 cd/m² |
| kontraste-erlazioa | 1200:1 (Typ.) (TM) |
| ikuspegi angelua | 89/89/89/89 (Typ.)(CR≥10) |
| bistaratzeko modua | ADS, Normally Black, Transmissive |
| ikuspegirik onena | Symmetry |
| erantzun denbora | 8 (Typ.)(G to G) |
| beiraren sakonera | 0.50+0.50 mm |
| transmisibitatea | 5.4% (Typ.)(with Polarizer) |
| bistaratzeko koloreak | 1.07B 72% NTSC |
| lanpara mota | No B/L |
| maiztasuna | 60Hz |
| pantaila taktila | Without |
| gidariaren ic | COF Built-in 6 source chips |
| panelaren pisua | 2.60Kgs |
| aplikazio | TV Sets |
| seinale interfazea | V-by-One 8 lane , 51 pins Connector |
| sarrerako tentsioa | 12.0V (Typ.) |
| ingurunea | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
