| PartZenbakia | ASI545FB01-0 |
| Marka | Samsung |
| Tamaina | 55 |
| Aplikazio | DID |
| Ebazpena | 1920×1080 |
| Konposizioa | OLED |
| Distira | 500 |
| CR | |
| Koloreak | 1.07B |
| Atzeko argia | self |
| Interfazea | LVDS |
| panel marka | SAMSUNG |
| panel eredua | ASI545FB01-0 |
| panel mota | TOLED , OLED |
| panelaren tamaina | 55 inch |
| ebazpena | 1920×1080(RGB) , FHD |
| eremu aktiboa | 1209.6×680.4 mm |
| eskema | 1219.4×697 mm, Videowall Seam 9.8 mm |
| azalera | Hard coating (2H), Antireflection |
| distira | 500 cd/m² (Typ.) |
| kontraste-erlazioa | |
| bistaratzeko koloreak | 1.07B (10-bit), CIE1931100% |
| ikuspegi angelua | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| maiztasuna | 60Hz |
| seinale interfazea | LVDS (2 ch, 10-bit), 51 pins |
| sarrerako tentsioa | 12.0V (Typ.) |
| aplikazio | DID |
